Feature:
1. 40GBPS VIDEO BANDWIDTH: HD Multimedia Interface switch supports video resolutions up to 8K at 60Hz 4:2:0 10bit, 8K at 30Hz 4:4:4 10bit, 4K at 120Hz 4:4:4 10bit. 40Gbps video bandwidth is supported.
2. EDID MANAGEMENT: Support EDID management and sound de embedding function (via optical and analog port output). Support VRR, FVA, ALLM and HDR, HDR10, HDR10+, for Dolby Vision, HLG pass through technology.
3. SOUND FORMAT SUPPORT: 8K HD Multimedia Interface switcher supports LPCM, for Dolby Digital Plus EX, for Dolby True HD, DTS, DTS EX, DTS 96 24, DTS High Res sound formats.
4. BUILT IN EQUALIZER: 2x2 HD Multimedia Interface switcher has built in equalizer, retiming and drivers, and supports IR remote control and front panel button switching.
5. 2X2 HD MULTIMEDIA INTERFACE SWITCHER: Video switcher can not only switch between either of the two HD Multimedia Interface input signals, but can also assign them to two displays simultaneously.
6. SCOPE OF APPLICATION: HD Multimedia Interface switcher is used for presentations, video conferencing, multimedia teaching and other applications that require large screen presentations.
Specification:
Item Type: HD Multimedia Interface Switcher
Material: Iron Box
HD Multimedia Interface Compliance: HD Multimedia Interface 2.1
HDCP Compliance: HDCP 2.3
Video Bandwidth: 40Gbps
Video Resolution: Up To 8K At 60Hz 4:2:0 10bit, 8K At 30Hz 4:4:4 10bit, 4K At 120Hz 4:4:4 10bit
Color Depth: 81012 Bit
Color Space: RGB, YCbCr 4:4:4, 4:2:2. YUV 4:2:0
HD Multimedia Interface Input And Output Formats: LPCM, For Dolby Digital Plus EX, For Dolby True HD, DTS, DTS EX, DTS 96 24, DTS High Res
Optical: LPCM 2 5.1 CH, For Dolby Digital 2 5.1 CH, DTS 2 5.1 CH
Analog: PCM 2.0
ESD Protection: Mannequin +- 8 KV (Air Gap Discharge) +- 4 KV (Contact Discharge)
Input: 2 x HD Multimedia Interface IN (Type A, 19 Pin Female)
Output: 2 x HD Multimedia Interface OUT (Type A, 19 Pin Female), 1 x OPTICAL (S PDIF), 1 x L R (3.5mm Stereo Mini Jack)
Control: 1 x SERVICE (Micro USB, Update Port)
Voltage: 100-240V
Remote Control Battery Type: 1 x CR2025 Button Cell (Not Included)
.
Package List:
1 x
HD Multimedia Interface Switcher1 x Power Adapter1 x Remote Control1 x Instruction Manual
