Video Input : 32 Channel
Resolution : 5mp
TV System : NTSC,PAL
PCS of Camera : 16pcs
Cable Length : None
Model Number : DM29SP-AI-50G/80N
Brand Name : Techage
Origin : Mainland China
Certification : CE
Smart home platform : Other
POE NVR : H.265 16CH 8MP POE NVR
Camera Features : Plastic Case, Indoor Outdoor Waterproof
Camera Lens : 3.6mm default
Alarm System : Motion Detection + Email Alert +APP Push
Mobile Phone Viewing : Yes via XMEYE Pro APP
Hard Disk Drive (HDD) : 1*SATA Port (support up to 16TB)
Language : Support Multi language(English,Spanish,Russian etc.)
Advantage : 2 White Lights + 2 Infrared Lights
AI Camera : Face Human Body Motion Detection
Two-way Audio Camera : Bulit in Microphone and Speaker
Smart AI : Full Color Night Vision and Red-Blue Flashing Light Alert
8.0MP POE : 3840*2610px
5.0MP POE : 2592*1944px
New Upgrade:
* Our NVR And Cameras All Are H.265。
* All Cameras Are Built-In Microphone And Speaker, Support Two-Way Audio Sound Recording.
* Human Detection : Only Detected Human Movement, Reduce False Alarm Messages.
* Customized Voice Alarm: Reasonably Customize The Alarm Area You Want, Voice Alert.
* Double Light Night Vision: The Camera Can Be Set To Full Color Night Vision Like Day Vision.
* Support Red-Blue Flashing Light Alert。
Real-time Two-way Audio Communication Camera Has Built In Microphone And Speaker,Never Miss a Moment With Your Family.
AI Human Detection and Red-Blue Light Alarm At the day time, when human detected, the red light and blue light will flash alternately to scare off intruders, and 2pcs white lights will light, serve as a warning deterrent. APP notification and E-mail will be pushed to your phone or mailbox.
9 Kinds Alarm Sound for Option ( Only Support English Sound )When Someone Breaks Into Shooting Area,The Camera Will Make Alarm Sound Alarm Messages Will Be Pushed To Your Phone App.
Intelligent Identification Alarm Only When Someone Pass The Alarm Area , The Camera Will Send Alarm Message , Increase Alarm Accuracy.
Face Record/Face Detection/Face Playback Record Every Face That Appears On The Lens, Without Missing Any Details.
Smart IR-Cut Colorful Night Vision When The 2 White Leds Lighting, The Camera Will Show Colorful Vision At Night,There Are Three Night Modes For You To Select.
Support 5MP/8MP HD Display Show Higher-Quality Images, With Better Experience.
H.265 POE CCTV System H.265 More Clear , Hd Resolution Offer You Best Image Quality In a Lower Bit Rate.Save More Storage Space,Can Reduce 40%-50% File Size,Save Your Hdd Storage Space And Reduce Your Purchase Cost.
POE Advantage, Why Choose POE ?Don't Need Extra Power Cables or Adapters. Plug And Play And Easy Setup.
Max Support 100 Meters Cables Transmission Distance Which Greatly Increases Home Installation Convenience.
Install and Connect it It can be quickly and easily setup by anyone. Instantly see live video using your computer, tablet, or phone from anywhere.Don't need extra power cables or adapters or switch.
Video With Smart Playback Smart Playback Available With Customizable Searching Area,Playback Time Is Greatly Reduced By Speeding Through Unimportant Videos.
IP66 Waterproof Security Camera Our Camera All Can Suit For Both Outdoor And Indoor Usage.
Remote Access Anytime, Anywhere
Based On P2P (Peer To Peer) Technology, Support Plug-And-Play Installation.
Access The Ip Camera Through Its Web Interface Via Internet Explorer,
Also Comes With a Free Smartphone App (Android & Iphone) For Remotely View From Anywhere.
Support IOS And Android Device Access. Scan QR-Code To Login. Download Free App In Apple App Store / Google Play.
4K 32CH NVR Specifications:
Main processor:Hi3536C
Operating System:Embedded Linux
System resources:Simultaneous multi-channel real-time recording, playback, network operation, USB backup
Interface
Operator interface:16-bit true color graphic menu operation interface, support mouse operation
Preview:1/4/9/16/32
Video
Video input (IP):32CH4K
Access bandwidth:300Mbps
Forwarding bandwidth:240Mbps
Video compression:H.265/H.264
Display quality Max:4K
Playback quality:4K/5M/1080P
Decode:1*4K/2*5M/4*1080P
Motion detection:Support(depend on camera)
Audio
Audio compression:G.711A
Intercom:support
Record&playback
Recording mode:Manual>Alarm>Dynamic Detection>Timing
Local payback:1*4K/2*5M/4*1080P
Search mode:Search by Time/Calendar/Event/Channel
Record storage:HDD、Network
Backup mode:Network backup, USB hard disk, USB burner, SATA burner
External interface
Video output:1ch VGA，1ch HDMI HD output
Audio I/O:1/1
Alarm I/O:0/0
Network interface:1*RJ45 10M/100M/1000M Adaptive Ethernet port
USB interface:2*USB2.0 ports
HDD:1 SATA(Up to 8TB for each disk)
ESATA:No
Serial interface:No
Other
Power supply:12V/2A
Power Consumption:<10W(Without HDD)
Work environment:Temperature:0℃-＋55℃ , Humidity:10%－90%RH , Atm:86kpa－106kp
Weight:2.6kg
Package Include
1 x H.265 32CH 8MP Poe NVR
16/24/32 x 5MP/8MP Poe IP Cameras With Two-Way Audio
1/2 x 16CH POE Switch
1 x Power Supply For NVR(EU Plug,US Plug,UK Plug,AU Plug,optional)
1 x USB Mouse For NVR
1 x User Manual
2 x Warning Sticker ( Gift )
16/24/32 x Waterproof Connector For Cable (Gift)
1 X Remote Control (No Battery)
No HDD Or 3TB/4TB HDD For Optional
Note : Don't Include Network Cables for Cameras.
32CH POE NVR + 16 Cameras / 32CH POE NVR + 24 Cameras/ 32CH POE NVR + 32 Cameras For Optional
