The SV405CC astronomical camera adopts a back-illuminated IMX294 sensor with high quantum efficiency (peak QE is estimated to be over 75%) to improve sensitivity and reduce noise.
Built-in 256MB DDR3 high-speed memory for buffering image data, stable data transmission and no frame loss, effectively reducing the glow effect caused by slow reading speed.
On-board HCG mode - When the gain is set above 120, HCG mode is automatically enabled, effectively reducing reading noise without losing dynamic range.
TEC semiconductor two-stage cooling system: reduces the temperature difference of the CMOS sensor to 30° from ambient temperature, reduces the generation of dark current, and has very low noise even during long exposures of several hundred seconds. With 14-bit ADC digital-to-analog conversion, it can reach 13-bit dynamic range, which is very suitable for deep space photography.
SV405CC works on Windows, Linux, Mac OS, Chrome OS, and RaspberryPi systems by running AstroDMx Capture. For Windows systems, software such as Sharpcap, N.I.N.A., and TheSkyX are also supported to run on the ASCOM platform using ASCOM drivers.
Description SV405CC is an SVBONY brand deep space camera. Designed with SONYIMX294 color CMOS sensor, recommended for amateur astronomers. Here are some highlights: 1. Back-illuminated sensor – increased sensitivity and reduced noise 2.4/3-inch format with 4.63um pixel size – ideal for many types of telescopes 3. 14-bit ADC – provides a high dynamic range of 13 stops 4. Impressive 63ke – full-well capacity – helps reduce problems with saturated stars, for example. 5.HCG Mode - When you set the gain above 120, HCG mode is automatically enabled to reduce read noise to sweetheart level without losing dynamic range. 6.Outstanding low-light performance with SNR1s: 0.14 lx is achieved by using a large optical system and increasing the area per pixel to 4.63um. This makes the IMX294 ideal for applications in the security camera market that require low lighting performance. 7. IMX294 sensor adopts 4/3 format, required for true 4k output at 120 frames/second
Provides pixel count (using ADC 10-bit output mode; SV405CC can run up to 19fps in 4k format; USB 3.0). Features 1. Cooling System Thanks to two-stage TEC cooling, SV405CC can keep the CMOS sensor temperature 30℃ lower than the ambient temperature. This significantly reduces dark current generation and sensor noise even during long exposures. 2.Support System SV405CC camera works with Windows, Linux, Mac OS, Chrome OS, and RaspberryPi systems by running AstroDMx Capture. For Windows systems, it also supports Sharpcap, N.I.N.A., TheSkyX and other software running through the ASCOM platform using ASCOM drivers. Specifications Model: SV405CC Sensor: SONY IMX294 CMOS Image resolution: 4144 * 2822 Total number of pixels: 11.7 megapixels Pixel size: 4.63μm Target size: 19.2mm * 13mm
Diagonal: 23.2mm Maximum frame rate: 19FPS Shutter type: Rolling shutter USB type: Type B USB 3.0 DDRIII buffer: DDR3 256M Exposure: 0.05ms-2000s Read noise: 1.2e QE peak: 75% Full well: 63ke ADC: 14 bits Temperature display: Displayed by software Cooling system: TEC semiconductor two-stage refrigeration Digital noise reduction: Support ROI: Any supported resolution Pixel binning: BIN1, BIN2, BIN3, BIN4 Operating system: Windows, Linux, Mac OS, Chrome OS Protective window Optical glass: AR coating Camera interface specifications: 2″/1.25″/M42X0.75 Back focus distance: 6.5mm Operating current:
